SKILFUL SERIES SINTERED
<
>

Segment Diamond Cutting Wheels

7.0x2.2x20

  • Code:230
The use of diamond blades is rapidly growing as people become increasingly more knowledgeable and experienced, demanding better _ nishes and faster results. With an in depth knowledge of the construction and building industry Flexovit provides a range of diamond blades to meet any demand.
  • Share:

Details

Material:
Universal wheel for concrete, old reinforced concrete slabs, roofing pantiles, granite, natural slabs, roofing pantiles, granite, natural stones, pumice stones, lime stones, structural plaster, concrete tiles, bricks linker.
Application:
Cutting of bricks, slabs, clinker, moulded bricks, steps, stone-window-sills, roof coverings, structural plaster, concrete tiles.
Characteristics:
The very high diamond concentration enables very short cutting time with excellent life as well as shorter cooling breaks. Dry and wet cutting.


Technical Information

The use of diamond blades is rapidly growing as people become increasingly more knowledgeable and experienced, demanding better _ nishes and faster results. With an in depth knowledge of the construction and building industry Flexovit provides a range of diamond blades to meet any demand.
All Flexovit diamond blades conform to the highest European safety standard, EN13236, which ensures that all products are manufactured and tested to the highest quality. All Flexovit products are laser-marked in accordance with the requirements of EN13236.

APPLICATION
Where greater differentiation of products by application is needed, this is done through colour coding.
PERSONAL PROTECTION
Never exceed the Maximum Operating Speeds:
Hand held blades Φ ≤230mm: 80m/s
Hand held blades Φ> 230mm: 100m/s
Others : 63m/s



Dimension Height Thickness Bore PK Qty
MM MM MM MM

105

7.0/10.0

2.2

20/16 1
115 7.0/10.0 2.2 22.23/20 1
125 7.0/10.0 2.2 22.23/20 1
180 7.0/10.0 2.4 22.23/20 1
230 7.0/10.0 2.6 22.23/20 1
