Roller Wheels
75x6
Code:PRW7506A
Alumina abrasive for conventional circular grinding.
Share:
Alumina abrasive for conventional circular grinding
superior durability and efficiency
For flexible shafts, electric and pneumatic tools



Product Advantages

Application



Usage Advice

Flexible structure to meet the needs of the workpiece contour and shape
Open-ended material can be prevented from clogging hot corrosion under high pressure.
Without corrosive residues on the wrokpiece surface


Removing rust, corrosion spots, dirt, stubborn paint spots, or chemical residues, old coating glue, sealant, gasket residue
Cleaning welds and blueing material, especially the blueing stainless steel surface after hot-corrosion.
Cleaning the Filler surface


Mounted wheels will achieve the best grinding performance under 15-20M / S speed, with fine surface, low temperature of the workpiece, and the best balance.
Factors Affecting Grinding Effect
Tool wear and workpiece temperature load   Material removal rate   Surface roughness
Reducing grinding pressure and the circumferential speed , Also adding lapping oil can reduce tool wear and workpiece overheating   To achieve higher removal rates, a more coarse grit was recommended to use ,rather than increase the contact pressure, as the pressure will cause the tool to be excessive wear and overheating   Using high operation speeds to be the more smooth surface. But to increase the contact pressure will be more coarse surface
Safety Notes
To ensure safety, Please do not exceed the marked maximum speed













Size Grades
Available
PCS/BOX PCS/CTN M/S EAN-CODE
Dia Material
75x6 Aluminum
Oxid

Purple
Blue
Black

12 120 80m/s PRW7506A
90x6(12) 12 120 80m/s PRW9006(12)A
100x12 10 100 80m/s PRW10012A
115x12 10 100 80m/s PRW11512A
125x12 10 100 80m/s PRW12512A
150x12 10 100 80m/s PRW15012A
180x12 6 70 80m/s PRW18012A
200x12 5 60 80m/s PRW20012A
