IDENTIFYING INFORMATION

Product Line

PEGATEC cutting wheels with the perfect cutting result.

There are 4 product lines with different performance and feature. Respective direct at customer group、type of drive tools and processing task.



High-performance And
Multipurpose.

■ Multipurpose cutting

■ Superior durability

General purpose

■ Common processing and hand finishing

■ Sharp、Easy

High-performance

■ Widely used in industrial
processing

■ Sharp、Durable

Low-cost type

■ For common processing

■ Durable, Low cost



Each series with the differentiation of high cost and performance, which can meet the processing task and purchase cost of different worldwide industries completely. And certainly you will find the best cutting wheels for different appliance.



P         80         41         115         1         SS

1           2           3           4           5           6

 1.
P
 (Brand short name) SPC= SCISSORSHAND   P= PEGATEC         S = SKILFUL
2.
80
 Running speed  80=80M/S  70=70M/S
3.
41
 41=Flat cutting wheels    27=Grinding wheels     42=Depressed centre cutting wheel
 4.
115
 Diameter   115=4.5”
 5.
1
 Thickness   1 = 1,0mm  -  1,2mm
6.
SS
 SS=Stainless Steel   S=Concrete、Stone  M=Steel     A=Aluminum、Copper product







Identification of certificate





Abrasives



A           60           T           BF           41

1             2             3             4             5

1
A

A = Aluminum Oxide Z = Zirconia alumina

C = Silicon carbide ZA = Zirconia alumina & Aluminium Oxide

2
60
 Grain Size of abrasives
3
T
 Hardness Grade     According to the ascending order of the alphabet, A-Z from soft to    extremely hard.
4
 BF
 Bond (Resin Bonded)
5
41
 41=Flat cutting wheels    27=Grinding wheels

42=Depressed centre cutting wheel



Color Code System

Color code for various work-piece (identify the applicable to the work-piece, just look at the color.)





Material group

PEGATEC Series



Material group

SKILFUL Series



Material group

SCISSORSHAND
Series

  STEEL   STEEL

STEEL

STAINLESS STEEL

CONCRETE & STONE

CAST IRON

ALUMINIUM

  STAINLESS STEEL   STAINLESS STEEL

Material group

4 IN 1

  CONCRETE
& STONE
  CONCRETE
& STONE


STEEL

STAINLESS STEEL

CAST IRON

ALUMINIUM

  CAST IRON   CAST IRON
  ALUMINIUM   ALUMINIUM
